Huawei Power-M 5kW Power Module Inverter + 15kWh Battery
Same Day Delivery
| Power module | iSitePower-M |
| Output/Input Power Per Module | 5kW |
| Battery module capacity | 15kWh |
| Display | SOC Status Indicator |
| Communication | CAN (for parallel communications), WLAN/FE/4G (for the SmartPVMS) |
| Battery module dimension (WxHxD) | 700mmx390mmx158mm |
| Battery Module Weight | 50KG |
| Power module dimensions (WxHxD) | 700mmx246mmx152mm |
| Power module weight | 17KG |
| Base dimension (WxHxD) | 700mmx65mmx147mm (floor installed) and 643mmx110mmx176mm (wall-mounted) |
| Base weight | 1.5KG (floor installation) / 5.5KG (wall-mounted) |
| IP Rating | IP66 |
| Cell technology | Lithim-iron phosphate (LiFePO4) |
| Input voltage | 200/208/220/230/240V AC |
| Input current | Max.30A |
| Frequency | 50/60Hz |
For Bulk Orders
Call (020) 14536190.
Comes with 3 batteries.
Excellent performance:
Ultra-fast: 3-hour fast charge 100%
Ultra-quiet: Fan less design, operating noise less than 29 dB
Energy switchover without perception<10ms
Smart priority management (Solar /battery /grid /DG)
Smart mobile APP management: monitor device running status in real time, help EPC & client efficiently manage device.
D.G. scheduling is supported, D.G. does not need to be started manually.
Built-in energy optimizer, supporting mixed use of old and new lithium batteries
Secure and Reliable:
90–300 V, withstand voltage jump
1.5 times the shock of the device startup current (air conditioner, washing machine, and motor)
0 Second Fast shut down (solar PV modules’ voltage can be quickly shut down to 0 V within 0s，Ensure the safety: the owner, installation and maintenance personnel)
IP65 dustproof & waterproof ( indoor /outdoor)
Matrix Design Heat Dissipation
AFCI function
Most stable LFP Battery, no fire risk
Battery built-in full-dimensional high-precision sensors
